WLL[t] |
Minimum Tensile Strength[kN] |
E[mm] |
D[mm] |
F[mm] |
B[mm] |
A[mm] |
L[mm] |
Weight[kg/pieces] |
Welda min[mm] |
|
|
1,12 |
43,9 |
63 |
13,5 |
37 |
40 |
38 |
37 |
0,40 |
10 |
|
|
2,0 |
78,5 |
73 |
14,5 |
42 |
42 |
40 |
40 |
0,45 |
12 |
|
|
3,15 |
124,0 |
75 |
17,5 |
42 |
45 |
43 |
44 |
0,75 |
14 |
|
|
5,3 |
208,0 |
94 |
22,5 |
56 |
55 |
60 |
49 |
1,45 |
18 |
|
|
8,0 |
314,0 |
112 |
27 |
62 |
69 |
70 |
66 |
2,35 |
22 |
|
|
15,0 |
588,0 |
154 |
34 |
86 |
96 |
88 |
88 |
5,35 |
30 |
Method of lifting |
|
|
|
|
|
|
|
|
|
|
|
Number of chain |
1 |
2 |
3/4 |
2 |
3/4 |
||||||
Angle of inclination |
0° |
90° |
0° |
90° |
0-45° |
45-60° |
0-45° |
45-60° |
asymetry |
||
|
|
WLL [kg] |
||||||||||
|
|
1 120 |
1 120 |
2 240 |
2 240 |
1 600 |
1 120 |
2 360 |
1 700 |
1 120 |
1 120 |
|
|
|
2 000 |
2 000 |
4 000 |
4 000 |
2 800 |
2 000 |
4 250 |
3 000 |
2 000 |
2 000 |
|
|
|
3 150 |
3 150 |
6 300 |
6 300 |
4 250 |
3 150 |
6 700 |
4 750 |
3 150 |
3 150 |
|
|
|
5 300 |
5 300 |
10 600 |
10 600 |
7 500 |
5 300 |
11 200 |
8 000 |
5 300 |
5 300 |
|
|
|
8 000 |
8 000 |
16 000 |
16 000 |
11 200 |
8 000 |
17 000 |
11 800 |
8 000 |
8 000 |
|
|
|
15 000 |
15 000 |
30 000 |
30 000 |
21 200 |
15 000 |
31 500 |
22 400 |
15 000 |
15 000 |
|
